CS4&CS6 Street edition

Designed for daily street use and track-day, CS series can improve the performance, aesthetics and comfort of the brakes on your car.

Specification

CS4 Caliper	CS6 6 Pistons Caliper
Manufacturing process： 2-piece Forged	Manufacturing process： 2-piece Forged
Qty of piston： 4 pistons	Qty of piston： 6 pistons
Rim Size： 18”	Rim Size： 19”
Color： Red/Yellow/Black/Silver	Color： Red/Yellow/Black/Silver
Rim Size(Inch)： Disc(mm)：	Rim Size(Inch)： Disc(mm)：
18”(Front) 355X34 18”(Rear) 355X28 19”(Rear） 380X28	19”(Front) 380X34 20”(Rear) 400X34

Disc Face Types

CS6 road caliper

The forged caliper is made of aviation aluminum. The shape of the caliper adopts multiple hollow and lightweight designs to minimize the weight of the caliper.

The asymmetrical design is more in line with the principle of braking dynamics, and has better ventilation and heat dissipation performance.

CS series caliper features differential bores and high temperature seals and piston dirt seals to protect against ingress of harmful debris.

CS6 caliper suits 380/410x34 mm discs

High carbon 72V brake disc

The new pattern design increases braking friction and effectively reduces power frequency noise. The unique patented design of 72 ventilated vanes provides more efficient cooling effect.

The carbon content is as high as 3.83%, and metal elements such as silicon and manganese are added to improve the fatigue resistance and wear resistance Heat treatment removes internal stress, reduces distortion and vibration.

INSPEED PAD

In order to get the best performance and comfort from brake system. INSPEED choose low metal formula with silicon carbide, alumina and other available friction materials to prevent judder or break squeal.

Rigorous LINK testing, simulating a variety of extreme environments, INSPEED PAD represents excellent initial performance, high temperature performance, more stable under continuous braking.

INS-10 series friction μ 0.38-0.43, Temperature 0-500 degrees centigrade

INS-20 series friction μ 0.38-0.47, Temperature 0-800 degrees centigrade

HEL Stainless steel braided brake lines

Manufactured by HEL Performance , HEL stainless steel brake line are certified:

ISO9001，SAE

FMVSS-106

NHTSA

DOT

TUV/Derka/KBA

ADR

INSPEED BELLS AND BRACKETS

CNC machined Aviation alum bells and steel brackets.

INSPEED H-Bobbin rotor attachment complete hardware kit for floating 2-piece rotors

H-Bobbin rotor attachment complete hardware kit for floating 2-piece rotors. Corrosion resistant, allows secure mounting, and smooth expansion and contraction throughout heat cycles
